| Article number: | GK-T6-SL-02K |
available options:
- grille integration kit with ST 4 EVOLUTION (highline/trendline models only)
- grille integration kit with LED Triple R 750 high performance
- grille integration kit with LED Triple R 750 ELITE (wth E-Boost)
For an OE quality, auxiliary spotlight installation, the Lazer Grille Integration Kits include bespoke mounting brackets which allow for quick and easy fitting of Lazer High Performance LED Spotlights within the front grille of the most popular road cars, pick-up trucks, and light commercial vehicles. Designed to blend seamlessly within the original styling of each vehicle, the resulting lighting setup remains fully robust and secure, with extra protection against theft.
The VW T5 (2010+), designed for 2014 vehicles onwards, includes a pair of Triple-R 750 High Performance LED driving lights, plus wiring kit, alongside 4x brackets precision-engineered to engage perfectly with the standard centre grille on the vehicle. Made from ASA material, known for its excellent strength and UV stability, the brackets are fully weather and chemical resistant to ensure your installation remains in great condition year after year.
With lighting performance borne out of development and testing work done at the highest levels of professional motorsport, despite the sleek styling and seamless integration, it is at night when the installation really impresses. Complete with Triple-R 750 Std, the kit boasts 8,200 raw lumens, delivering 1 lux to over 600m; lighting performance that needs to be seen to be believed, but still within ECE regulations, meaning the lights can operate with your standard high beam driving lights.
Supplied alongside the mounting brackets are a set of cutting guides, designed to facilitate the installation and ensure a perfect fit everytime.
What's included:
- x2 Triple-R 750 High Performance LED Spotlights
- x1 Mounting Kit (comprising 4x Brackets and fasteners)
- x1 Cutting Guide (comprising 4x Brackets)
- x1 Two-Lamp Wiring Kit
- x1 Installation instructions
MADE IN THE UK
Where the vehicle has LED headlights as standard, it may not be possible to detect a 12V high beam signal. In these instances, and where the lights want to operate with the standard high beam driving lights, it will be necessary to complete the electrical installation using a CanM8 High Beam Interface.
Based on standard setup i.e. x2 Triple-R 750 High Performance LED Lamps:
| E-Mark Ref | 27.5 x2 |
| Voltage Range | 9-32V |
| LED Life | 50,000 hours |
| Optical Efficiency | 92% |
| Weight | 2 kg |
| HIGH BEAM FUNCTION | |
| Total Luminous Flux | 8200 Lm |
| Number of High Output LEDs | 2 x 4 |
| Power Consumption | 90 Watts |
| Current Draw (at 14.4V) | 6.2 Amps |
| CERTIFICATION | |
| High Beam | ECE R112 |
| PHOTOMETRIC DATA | |
| 0.25 lx Line | 1214 metres |
| 0.5 lx Line | 858 metres |
| 1 lx Line | 607 metres |
| 3 lx Line | 350 metres |
